CEN-60-12 is a 60W 12V 5A Single Output LED Lighting Power Supply with 90 ~ 295VAC input voltage. Features of this Mean Well power supply include built in active PFC function, IP66 design protecting the components from dust and moisture damage and making it usable for indoor and outdoor applications. High efficiency up to 86%, cooling by free air convection allowing a working temperature of -30 ~ +70°C and standard safety protections including short circuit, over current, over voltage and over temperature.
Additional Information
| Current (A) | 5A |
|---|---|
| Function | Constant Voltage |
| Features | Universal AC input / Full range (up to 295VAC) Protections: Short Circuit / Over Current / Over Voltage / Over Temperature Output voltage and constant current level adjustable Built-in active PFC function IP66 design for indoor or outdoor installations Cooling by free aire convection 100% full load burn-in test Suitable for LED lighting and moving sign applications Compliance to worldwide safety regulations for lighting Suitable for dry / damp / wet locations |
| Voltage (V) | 12V |
| Type | AC-DC |
| Technology | Switchmode |
| Power (W) | 60W |
Downloads
Product Datasheets
-
CEN-60 Datasheet Size: (444.35 KB)
