Details
DDR-120B-48 is a 120W 48V 2.5A din rail DC-DC converter with 16.8 ~ 33.6VDC input voltage. With compliance to EN50155 and EN45545-2 railway standards the DDR-120B-48 is suitable for applications including bus, tam and railway systems, industrial control systems and factory automation.
Additional Information
| Current (A) | 2.5A |
|---|---|
| Function | Constant Voltage, DC-DC |
| Features | Compliance to EN50155 and EN45545-2 railway standard Width only 32mm 2:1 wide input range Wide working temperature range 150% peak load capability DC output adjustable Cooling by free air convection Can be installed on Din rail TS-35/7.5 or 15 Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection 4KVdc I/O isolation |
| Voltage (V) | 48V |
| Type | DC-DC |
| Technology | Switchmode |
| Power (W) | 120W |
Downloads
Product Datasheets
-
DDR-120 Series Datasheet Size: (198.75 KB)
