Details
DDR-60G-12 is a 60W 12V 5A din rail DC-DC converter with 9 ~ 36VDC input voltage. The DDR-60G-12 offers a 4:1 ultra wide input range as well as an adjustable DC output (±10%)
Additional Information
| Current (A) | 5A |
|---|---|
| Function | DC-DC |
| Features | Width only 52.5mm (3SU) 4:1 ultra wide input range Wide working temperature range No minimum load required DC output adjustable (+/- 10%) Cooling by free air convection Can be installed on Din rail TS-35/7.5 or 15 Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection 4KVdc I/O isolation |
| Voltage (V) | 12V |
| Type | DC-DC |
| Technology | Switchmode |
| Power (W) | 60W |
Downloads
Product Datasheets
-
DDR-60 Series Datasheet Size: (124.01 KB)
