DRA-40-24 is a 40.8W 24V 1.7A Single Output Din Rail Power Supply with 90 ~ 264VAC input voltage. Features of this Mean Well din rail power supply include output adjustable through internal potentiometer, output current adjustable through external 1 ~ 10 Vdc, PWM signal or resistance, cooling by free air convection and LED indicator for power on. Applications for the DRA-40-24 include machine vision inspection systems and plant cultivation equipment.
Product Tags
Use spaces to separate tags. Use single quotes (') for phrases.
Additional Information
Current (A)
N/A
Function
N/A
Features
DRA-40-24 Features
Universal AC input / Full range Protections: Short circuit / Overload / Over voltage Can be installed on DIN rail TS-35/7.5 or 15 Built-in 3 in 1 dimming function (1~10Vdc or PWM signal or resistance Cooling by free air convection LED indicator for power on 100% full load burn-in test 3 years warranty
