SDR-120-12 120W 12V 10A Industrial DIN RAIL Power Supply with PFC Function

More Views

SDR-120-12 120W 12V 10A Industrial DIN RAIL Power Supply with PFC Function

SKU: SDR-120-12

Be the first to review this product

£48.54

Availability: In stock

Quick Overview

SDR-120-12 from Mean Well is a 120 Watt, 12 Volt, 10 Amp, single output industrial din rail power supply with 88 ~ 264VAC input voltage.



Details

SDR-120-12 is a 120W 12V 10A single output industrial power supply with PFC Function. This Mean Well din rail power supply features high efficiency of 90.5%, low power dissipation, 150% peak load capability, and been through 100% full load burn-in test. SDR-120-12 is suitable for applications such as industrial control system, semi-conductor fabrication equipment, factory automation, electro-mechanical appliances, telecommunication devices and marine applications.

Write Your Own Review

You're reviewing: SDR-120-12 120W 12V 10A Industrial DIN RAIL Power Supply with PFC Function

How do you rate this product? *

  1 star 2 stars 3 stars 4 stars 5 stars
Service
Price
Value
Quality

Product Tags

Use spaces to separate tags. Use single quotes (') for phrases.

Additional Information

Current (A) 10A
Function Constant Voltage, Power Factor Correction
Features

SDR-120-12 Features

High efficiency 91% and low power dissipation
150% peak load capability
Built-in active PFC function, PF > 0.93
Protections: Short circuit / Overload / Over voltage / Over temp
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
UL508 (Industrial control equipment) approved
EN61000-6-2 (EN50082-2) industrial immunity level
Built-in DC OK relay contact
100% full load burn-in test
3 years warranty

Voltage (V) 12V
Technology Switchmode
Power (W) 120W

Downloads

Product Datasheets

SDR-120-12 120W 12V 10A Industrial DIN RAIL Power Supply with PFC Function
