SDR-240-24 240W 24V 10A Industrial DIN RAIL Power Supply with PFC Function

More Views

SDR-240-24 240W 24V 10A Industrial DIN RAIL Power Supply with PFC Function

SKU: SDR-240-24

Be the first to review this product

£90.28

Availability: In stock

Quick Overview

SDR-240-24 from Mean Well is a 240 Watt, 24 Volt, 10 Amp, single output industrial din rail power supply with 88 ~ 264VAC input voltage and power factor correction.



Details

SDR-240-24 from Mean Well is a 240W 24V 10A industrial power supply with built-in active power factor correction function, 150% peak load capability, high efficiency of 94%, low power dissipation and cooling by free air convection. The SDR-240-24 is suitable for applications such as industrial control system, semi-conductor fabrication equipment, factory automation, electro-mechanical appliances, telecommunication devices and marine applications.

Write Your Own Review

You're reviewing: SDR-240-24 240W 24V 10A Industrial DIN RAIL Power Supply with PFC Function

How do you rate this product? *

  1 star 2 stars 3 stars 4 stars 5 stars
Value
Quality
Service
Price

Product Tags

Use spaces to separate tags. Use single quotes (') for phrases.

Additional Information

Current (A) 10A
Function Constant Voltage, Power Factor Correction
Features

SDR-240-24 Features

High efficiency 94% and low power dissipation
150% peak load capability
Built-in active PFC function, PF > 0.93
Protections: Short circuit / Overload / Over voltage / Over temp
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
UL508 (Industrial control equipment) approved
EN61000-6-2 (EN50082-2) industrial immunity level
Built-in DC OK relay contact
100% full load burn-in test
3 years warranty

Voltage (V) 24V
Technology Switchmode
Power (W) 240W

Downloads

Product Datasheets

SDR-240-24 240W 24V 10A Industrial DIN RAIL Power Supply with PFC Function
