Details
APC-8-700 is a 7.7W 6 ~ 11V 700mA Single Output LED Lighting Power Supply with universal AC input / full range. It is a small and compact, constant current design, class II (no frame ground) power supply unit, with cooling by free air convection, no load power consumption lower than 0.5W and built in protections including short circuit and over voltage. The IP42 rating means this unit is suitable for applications including indoor LED lighting, decorative and office LED lighting
Additional Information
| Current (A) | 700mA |
|---|---|
| Function | Constant Current |
| Features | Constant current mode power supply Universal AC input / Full range Class II (no frame ground) Protection: Short Circuit Fully isolated plastic case Small and compact size Cooling by free air convection No load power consumption <0.5W IP42 design 100% full load burn-in test Low cost / High reliability 2 years warranty |
| Type | AC-DC |
| Technology | Switchmode |
| Power (W) | N/A |
Downloads
Product Datasheets
-
APC-8 Series Datasheet Size: (113.91 KB)
