Details
ELG-75-12B is a 60W 12V 5A Constant Voltage and Constant Current mode output LED Lighting Power Supply with 100 ~ 305VAC input voltage from Mean Well. Features of the power supply include built in active PFC function, IP67 design for indoor or outdoor installations. 3 in 1 dimming (dim-to-off) function, high efficiency up to 85% and a typical lifetime greater than 50,000 hours. Compliance to worldwide safety regulations and standard safety protections including short circuit, over current, over voltage and over temperature.
Additional Information
| Current (A) | 5A |
|---|---|
| Function | Dimmable |
| Features | 48~75W Constant Voltage and Constant Current mode output Metal housing design with functional ground Built-in active PFC function Class 2 power unit No load / Standby power consumption <0.5W IP67 rating for indoor or outdoor installations 3 in 1 dimming (dim-to-off) function Typical lifetime > 50000 hours 5 years warranty |
| Voltage (V) | 12V |
| Type | AC-DC |
| Technology | Switchmode |
| Power (W) | 60W |
Downloads
Product Datasheets
-
ELG-75 Series Datasheet Size: (994.32 KB)
