DRT-960-24 Three Phase DIN Rail Power Supply from Power Supplies Online

More Views

DRT-960-24 960W 24V 40A Three Phase DIN Rail Power Supply

SKU: DRT-960-24

Be the first to review this product

  • Buy 10 for £185.21 each and save 28%
£257.23

Availability: In stock

Quick Overview

DRT-960-24 from Mean Well is a 960 Watt, 24 Volt, 40 Amp, AC/DC three phase wide range AC input, industrial din rail power supply unit with built in constant current limiting circuit.



Details

DRT-960-24 is a three-phase model that is powered by 340~550VAC 4 wire power system. Featuring a high efficiency up to 92%, the DRT-960-24 is cooled by free air convection which allows an operating temperature range of -20°C to +60°C and significantly increases the reliability and lifetime of the PSU. Built-in constant current limiting circuit means the DRT-960-24 possesses the ability to fulfill instant output surge current, which is common under heavy-industrial environments, and the optional parallel function can expand the output current up to 80A (24VDC) which also increases its installation flexibility. The DRT-960-24 meets EN61000-6-2 industrial immunity level and features built-in protections for short circuit, over load, over voltage and over temperature safety.

Write Your Own Review

You're reviewing: DRT-960-24 960W 24V 40A Three Phase DIN Rail Power Supply

How do you rate this product? *

  1 star 2 stars 3 stars 4 stars 5 stars
Quality
Service
Price
Value

Product Tags

Use spaces to separate tags. Use single quotes (') for phrases.

Additional Information

Current (A) 40A
Function Constant Voltage
Features

DRT-960-24 Features

  • Three-Phase AC 340-550V wide range input
  • High efficiency 91% and low dissipation
  • Short circuit, over load, over voltage & over temperature protections
  • Cooling by free air convection
  • Built-in constant current limiting circuit
  • Can be installed on DIN rail TS-35/7.5 or 15
  • UL 508 (industrial control equipment) approved
  • EN61000-6-2(EN50082-2) industrial immunity level
  • 100% full load burn-in test
Applications
  • Factory automation
  • Electro-mechanical industry
Voltage (V) 24V
Type AC-DC
Technology Switchmode
Power (W) 960W
Works with:
  • Factory automation
  • Electro-mechanical industry

Downloads

Product Datasheets

DRT-960-24 960W 24V 40A Three Phase DIN Rail Power Supply
