Details
DDR-15G-24 is a 15W 24V 0.63A din rail DC-DC converter with 9 ~ 36VDC input voltage. With a wide operating temperature range of -40°C to +85°C achieved through cooling by free air convection, built-in protections and an ultra slim design just 17.5mm wide, the DDR-15G-24 is suitable for a wide range of applications.
Additional Information
| Current (A) | <1A |
|---|---|
| Function | DC-DC |
| Features | Width only 17.5mm (1SU) 4:1 ultra wide input range Wide working temperature range No minimum load required DC output adjustable (+/- 10%) Cooling by free air convection Can be installed on Din rail TS-35/7.5 or 15 Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection 4KVdc I/O isolation |
| Voltage (V) | 24V |
| Type | DC-DC |
| Technology | Switchmode |
| Power (W) | 15W |
Downloads
Product Datasheets
-
DDR-15 Series Datasheet Size: (574.2 KB)
