Details
DDR-15G-5 is a 15W 5V 3A din rail DC-DC converter with 9 ~ 36VDC input voltage. The DDR-15G-5 has no minimum load requirement, a 4:1 ultra wide input range and adjustable DC output (±10%).
Additional Information
| Current (A) | 3A |
|---|---|
| Function | DC-DC |
| Features | Width only 17.5mm (1SU) 4:1 ultra wide input range Wide working temperature range No minimum load required DC output adjustable (+/- 10%) Cooling by free air convection Can be installed on Din rail TS-35/7.5 or 15 Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection 4KVdc I/O isolation |
| Voltage (V) | 5V |
| Type | DC-DC |
| Technology | Switchmode |
| Power (W) | 15W |
Downloads
Product Datasheets
-
DDR-15 Series Datasheet Size: (574.2 KB)
