Details
DDR-15G-12 is a 15W 12V 1.25A din rail DC-DC converter with 9 ~ 36VDC input voltage. With a width of just 17.5mm (1SU) for ideal installation, the DDR-15G-12 has a 4:1 ultra wide input range and a working temperature range of -40°C to + 85°C making it an ideal unit for industrial control systems, factory automation and wireless network communication systems.
Additional Information
| Current (A) | 1A |
|---|---|
| Function | DC-DC |
| Features | Width only 17.5mm (1SU) 4:1 ultra wide input range Wide working temperature range No minimum load required DC output adjustable (+/- 10%) Cooling by free air convection Can be installed on Din rail TS-35/7.5 or 15 Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection 4KVdc I/O isolation |
| Voltage (V) | 12V |
| Type | DC-DC |
| Technology | Switchmode |
| Power (W) | 15W |
Downloads
Product Datasheets
-
DDR-15 Series Datasheet Size: (574.2 KB)
