SDR-75-12 is a 75.6W 12V 6.3A single output industrial din rail power supply with 88 ~ 264VAC input voltage. Features of the SDR-75-12 din rail unit include 150% peak load capability, UL 508 approved (industrial control equipment), cooling by free air convection and 100% full load burn-in test. SDR-75-12 is suitable for applications such as industrial control system, semi-conductor fabrication equipment, factory automation and electro-mechanical applications.
Product Tags
Use spaces to separate tags. Use single quotes (') for phrases.
Additional Information
Current (A)
6A
Function
N/A
Features
SDR-75-12 Features
High efficiency 90% and low power dissipation 150% peak load capability Protections: Short circuit / Overload / Over voltage / Over temp Cooling by free air convection Can be installed on DIN rail TS-35/7.5 or 15 UL508 (Industrial control equipment) approved EN61000-6-2 (EN50082-2) industrial immunity level 100% full load burn-in test 3 years warranty
