WDR-240-48 240W 48V 5A Industrial DIN RAIL Power Supply

More Views

WDR-240-48 240W 48V 5A Industrial DIN RAIL Power Supply

SKU: WDR-240-48

Be the first to review this product

£120.30

Availability: In stock

Quick Overview

WDR-240-48 is a 240 Watt, 48 Volt, 5 Amp, single output industrial din rail power supply with 180 ~ 550VAC input voltage.



Details

WDR-240-48 is a 240W 48V 5A industrial power supply with single and two phase wide input range 180 ~ 550VAC input voltage. With built-in active power factor correction function, the WDR-240-48 offers high efficiency up to 91% and low power dissipation, making it an ideal din rail unit for a wide range of applications,

Write Your Own Review

You're reviewing: WDR-240-48 240W 48V 5A Industrial DIN RAIL Power Supply

How do you rate this product? *

  1 star 2 stars 3 stars 4 stars 5 stars
Value
Quality
Service
Price

Product Tags

Use spaces to separate tags. Use single quotes (') for phrases.

Additional Information

Current (A) 5A
Function Constant Voltage, Power Factor Correction
Features
  • Single and two phase wide input range 180 ~ 550VAC
  • Built-in active PFC circuit compliance to EN61000-3-2
  • High efficiency 91% and low power dissipation
  • Protections: Short circuit / Overload / Over voltage / Over temp
  • Cooling by free air convection
  • Can be installed on DIN rail TS-35/7.5 or 15
  • UL508 (industrial control equipment) approved
  • EN61000-6-2 (EN50082-2) industrial immunity level
  • 100% full load burn-in test
  • Built-in DC OK relay contact
  • 3 years warranty
Voltage (V) 48V
Technology Switchmode
Power (W) 240W

Downloads

Product Datasheets

WDR-240-48 240W 48V 5A Industrial DIN RAIL Power Supply
