Details
DDR-15G-15 is a 15W 15V 1A din rail DC-DC converter with 9 ~ 36VDC input voltage. With an adjustable DC output, no minimum load requirement and 4KVdc I/O isolation the DDR-15G-15 is ultra slim and can be installed on a TS-35/7.5 or 15 din rail
Additional Information
| Current (A) | 1A |
|---|---|
| Function | DC-DC |
| Features | Width only 17.5mm (1SU) 4:1 ultra wide input range Wide working temperature range No minimum load required DC output adjustable (+/- 10%) Cooling by free air convection Can be installed on Din rail TS-35/7.5 or 15 Protections: Short circuit / Overload / Over voltage / Input reverse polarity / Input under voltage protection 4KVdc I/O isolation |
| Voltage (V) | 15V |
| Type | DC-DC |
| Technology | Switchmode |
| Power (W) | 15W |
Downloads
Product Datasheets
-
DDR-15 Series Datasheet Size: (574.2 KB)
